1.Standard:IEC61008-1
2.Electromagnetic type
3.Prevent leakage accidents at the source
4.Precise in structure, less elements, without auxiliary power
5.Scenarios:industrial and mining enterprise, trade building,commerce and family
| Standard | IEC/EN 61008 | |
| Electrical features | Mode | Electro-magnetic type,electronic type |
| Type(wave form of the earth leakage sensed) | A,AC | |
| Rated current In | 16,25,32,40,63,80,100,125A | |
| Poles | 2P,4P | |
| Rated voltage Ue | AC 230/400V | |
| Rated sensitivity I△n | 0.01,0.03,0.1,0.3,0.5A | |
| Insulation voltage Ui | 500V | |
| Rated residual making and breaking capacity I△m | 1250A | |
| Short-circuit current I△c | 10000A | |
| Rated frequency | 50/60Hz | |
| SCPD fuse | 10000A | |
| Pollution degree | 2 |
| Standard | IEC/EN 61009 | ||
| Mechanical features | Electrical life | 4100 | |
| Mechanical life | 10000 | ||
| Protection degree | IP20 | ||
| Ambient temperature(with daily averages≤35°C) | °C | -25~+40 | |
| Storage temperature | °C | -25~+70 | |
| Installation | Terminal connection type | Cable/U-type busbar/Pin-type busbar | |
| Terminal size top for cable | mm² | 35 | |
| AWG | 18-3 | ||
| Terminal size top for busbar | mm² | 35 | |
| AWG | 18-3 | ||
| Tightening torque | N*m | 2.5 | |
| In-Ibs | 22 | ||
| Mounting | On DIN rail EN 60715(35mm) by means of fast clip device | ||
| Connection | From top and bottom |
