| Model | RES-200W100 | RES-215W100 |
| Battery Type | LiFePO4 | |
| Rated Charge/Discharge Performance | 0.5C | |
| Rated Voltage [V] | 716.8 | 768 |
| Operating Voltage Range [V] | 627.2~817.6 | 672~876 |
| Cell Rated Capacity [Ah] | 280 | 280 |
| Rated Capacity [kWh] | 200.7 | 215.04 |
| Composition | 1P224S | 1P240S |
| Rated Output Power [kW] | 100 |
| Max.Output Current [A] | 159 |
| Rated Grid Voltage [V] | 3/N/PE,230/400 |
| Rated Grid Frequency [Hz] | 50/60 |
| Power Factor Adjustable Range | 1(0.9 Leading~0.9 Lagging) |
| THDi | <3%(@Rated Power) |
| Rated Output Power [kW] | 100 |
| Max.Output Current [A] | 159 |
| Rated Output Voltage [V] | 3/N/PE,230/400 |
| Rated Output Frequency [Hz] | 50/60 |
| Unbalanced Load Capacity | 100% |
General Parameters
| Ingress Protection | IP54 | |
| Battery Cooling Method | Air conditioning cooling | |
| Relative Humidity | 0~95%,Non-condensing | |
| Temp.Range[℃] | -20~+50 | |
| Altitude[m] | 4000(>2000 Derating) | |
| Communication | RS485/CAN | |
| Communication Protocol | Modbus/IEC104 | |
| Weight [kg] | ≈2250 | ≈2450 |
| Dimension(W*D*H)[mm] | 1550*1235(1050)*2264 | |
| Delivery Method | Integral transportation | |
