| Table 1 | PHSF-40 | PHSF-125 | |
| Electrical features | Rated voltage | 240~415V | |
| Rated current | 16, 25, 32, 40A | 63, 80, 100, 125A | |
| Rated frequency | 50/60Hz | ||
| Poles | 1, 2, 3, 4P | ||
| Contact forms | 1-0-2 | ||
| Electrical life | 1500 cycles | ||
| Mechanical life | 8500 cycles | ||
| Protection degree | Ip20 | ||
| Ambient temperature | -25℃~+40℃ | ||
| Terminal/cable size | 16mm² | ||
| Mounting | On DIN rail EN60715(35mm) by means of fast clip device | ||
